Knife-Edge Optics Make This Blade A Cut Above!
Blizzard Lighting’s Blade™ RGBW Moving Head Beam combines blinding output, surgical precision and a razor-sharp 1.1 degree beam to dazzle your audience as it slices through the air!



Packed with 36 5-Watt CREE® Red/Green/Blue/White LEDs

and coupled to an all-new, incredible 1.1 degree beam angle optic system, the Blade™ RGBW is an incredible aerial performer packed in a tiny, lightweight package. Plus, thanks to advanced motor technology and innovative design, the Blade™ is the fastest, most accurate moving head we’ve ever offered... by far!

The Blade™ is a snap to program and easy on the eyes,

too, thanks to its full-color LCD-TFT display with icon-based navigation. Plus, the fixture has plenty of extras usually only found on fixtures with a much higher price tag. PowerCON™ compatible power in and out connectors make for secure power connections, user selectable 16-bit dimming, defeatable pan/tilt correction with trim adjustment, auto standby after DMX signal loss and fixture ID addressing are all included!



Finally the Blade™ RGBW

easily converts from a dazzling beam fixture to a versatile 8.8-degree soft-edged wash fixture by attaching the included diffuser lens. It’s like having two fixtures in one!

So get ready to slice and dice, and pick up your Blade™ RGBW’s



Features

•36x 5-watt R/G/B/W CREE® LED’s
•User selectable 11 or 15 DMX channels
•Razor-sharp 1.1° beam angle + attachable 8° diffuser lens
•4-button menu with LCD-TFT icon-based display
•Full color mixing in standalone, master/slave and DMX modes
•Built-in automated and sound active programs via master/slave
•User selectable 16-bit dimming
•Defeatable pan/tilt correction with trim adjustment
•Auto standby after DMX signal loss
•Fixture ID addressing
•3-pin male input and 3-pin female output
•PowerCon™ compatible AC power In/Out connectors

Blizzard Blade™ RGBW 36x 5W R/G/B/W CREE® LEDs

SKU: 123463
$659.00Price

Luminous Intensity:

69,000 lux @ 1M (10,200 lux with diffuser), 41,000 lux @ 2M (2,920 lux with diffuser)

OpticalLight source:

36x 5-watt R/G/B/W CREE® LEDsBeam Angle: 1.1° (8° with diffuser lens)MovementPan: 540º (8-16 Bit)Tilt: 240º (8-16 Bit)

ControlProtocol:

USITT DMX-512DMX channels: 11 or 15 channels3-pin DMX input/output

Operating modes:

standalone, M/S, sound active, color preset

PowerOperating voltage: 100-230VAC, 50/60 Hz

Power consumption: 148W, 1.84AFuse: 4A 250V

Dimentions

13.4" x 9.5" x 14.8"

Weight

11.5 lb

Warranty

2-year limited warranty, does not cover malfunction caused by damage to LEDs


DISCLAIMER:
The power connector fitted to the fixture and fixture cord are designed for compatibility with products manufactured by Neutrik AG, Neutrik USA and their related entities, however they are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik USA, or any related entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG.
